Designed to assist in the stripping of electric motors. This unit is not a burnout oven. If it smokes very much it's
probably overdone. Features a 1000 watt element and a 15 amp 250 volt plug.
|
|||||||||
 |
||||||||||
|
Pictured is a stator with heavy epoxy coating. Without heat this would be hard to strip and very time
consuming.
|
 |
|||||||||
 |
A chisel may break from time to time. This one happened to break on the epoxy coating.
|
|||||||||
|
The timer circuit is a double pole switch. The timer is there more as a precaution than the guideline of
time.
|
 |
|||||||||
 |
The element will get cherry red and very frangile when this hot. Do not touch element or pull wire while still on
stripper.
|
|||||||||
|
This unit warms stators in minutes for easy stripping. Pictured is a 1/4HP Specialy Coolant Pump motor.
Seven minutes from starting the heat element all coils were out. Time varies depending on varnish and size of motor.
|
 |
|||||||||
 |
On this 5HP High Speed Aluminum Case motor time usage was 20 minutes and all insulation came out as well.
|
|||||||||
|
Wires are easily pulled out of slots for rewinding.
|
 |
|||||||||
 |
Since the temperatures are reasonably cool you can start reinsulation before other methods have even
started to work.
|
|||||||||
|
This is an electric heater, there are no gas burners or heat lamps. No larger than a VCR, yet simple and
extremely effective.
|
|
|||||||||
|
The McCurdy Stator Heater can be purchased directly from McCurdy Motor Rewinding.
|
||||||||||
|
||||||||||
